Part No

Nose Dia.

Nose Length

Shoulder Dia

5015/1

6.30

6.30

7.94

5040

5.63

9.60

7.94

5042

6.15

9.6

7.94

5116

9.50

7.00

12.70

5277

6.60

14.40

7.94

Part No

O/All Length

Thread
Length

Dia or A/F

Thread

Conduit
Socket

9048

57

31

Swage

1/4” unf

6.60

9049

57

31

Swage

M6 x 1

6.60

9052

64

38

Swage

5/16” unf

6.60

9056

65

40

Swage

M8 x 1.25

6.60

9037

48

38

9.53 A/F

M8 x 1.25

6.60

9041

41

28

9.53 A/F

5/16” unf

6.60

9083

76

47

Swage

3/8" unf

6.60

5176

29

7.8

Swage

1/4” unf

6.60

Part No

 Dia.

 Length

5045/1

7.94

15.90

5136

7.94

39.23

5190

7.94

25.90
